Instruction Manual - Original Version
Page 20 of 50
To ensure the safe intended use of the printer, it needs to be installed and assembled according to the
following instructions.
Steps for installation:
1. Mapping and Anchoring
4. Mounting X-Axis
2. Mounting Z-Axes
5. Connecting cables
3. Mounting Y-Axes
5.4.1.1 Mapping and Anchoring
This section covers installation of Anchors, serving as a base for securing Z axes to the ground plane. The
procedure involves precisely mapping and marking where the anchors will be placed, drilling holes and
securing anchors with glue. Protective gear (gloves/mask/safety glasses) is required for drilling and while
handling Hilti glue.
Tools needed
• 16 x Hilti HIT-Z anchors
M16x240
• 1 x Laser measuring
device
• 1 x Angular laser
• 1 x Marker Pen
• 1 x Hammer Drill
• 1 x M8 Concrete drill bit
• 1 x M18 Concrete drill bit
• 1 x 3D printed drill guide
