Page 7For technical questions, please call 1-888-866-5797.Item 63890
Part Description Qty
1 8-channel H.264 DVR 1
2 Hard Drive (pre-installed) 1
3 3.6mm wide-angle indoor/
outdoor color camera with
infrared night vision
4
4 60 ft. camera cable 4
5 1-to-4 way splitter power cable 1
6 12V/2A power adapter for DVR 1
Part Description Qty
7 12V/2A power adapter
for 4pc camera
1
8 Mouse w/ USB cable 1
9 Remote Control 1
10 AAA battery 2
11 Mounting Screw 12
12 Mounting Anchor 12
12VDC/2A Power Adapter
Power
(to DVR)
Use the Mouse to
navigate the DVR
Mouse
Note: 2 AAA
batteries included
Remote
Remote Control Functions
1 - 8 Select Channel
0 Lock and Unlock Controls
ALL
Toggle between single, 4
and 8 Screen Displays
MENU Open Menu
MUTE Mute
SUBMENU Open Pop-Up Menu
▲ Menu Up
▼ Menu Down
◄ Menu Left
► Menu Right
SEL Confirm Selected Operation
◄◄ Rewind
► Play / Search Records
►► Fast Forward
● Record
ll Pause
■
Stop
Video
(from Camera)
Video
(to DVR)
Power
(to Camera)
Power
(from Splitter)
Cable - 60 ft.
Screws
Anchors
Mounting Hardware
12VDC/1A Power Adapter
Power
(to Splitter)
Power Splitter
Power
(from Adapter)
Power
(to Cables)
Record Serial Number Here:
Note: If product has no serial
number, record month and
year of purchase instead.
Note: Some parts are listed and
shown for illustration purposes
only, and are not available
individually as replacement parts.
Power
(from Cable)
Video
(to Cable)
Camera
Hood
Lens
