Page 6 For technical questions, please call 1-888-866-5797. Item 63890
Components and Controls
Read the ENTIRE IMPORTANT SAFETY INFORMATION section at the beginning of this
manual including all text under subheadings therein before set up or use of this product.
DVR Front Panel
1 2
3
1 Green Power Indicator - glows when power is on
2 Red Hard Drive Light - flashes when recording
3 USB Port
Figure B
DVR Back Panel
1
2
3
4
5
7
8
6
9
1 BNC Video Input 8
2 RCA Audio Input 4
3 RCA Audio Output 1
4 RJ45 LAN Ethernet Port 1
5 12VDC Power Input 1
6 USB 2.0 Port 1
7 HDMI Video Output 1
8 VGA Video Output 1
9 RS485 PTZ Connector 1
Figure C

Cobra 63890 Specifications

General

GPS	Yes
G-Sensor	Yes
Loop Recording	Yes
Channels	1
Remote Viewing	No
Motion Detection	Yes
Night Vision	Yes
Operating System	Not applicable
