Cobra CX50SR - Parts - Bars and Controls

20
Parts – Bars and Controls
Bars and Controls
REF # PART # DESCRIPTION
1 FAMU0014 HANDLEBAS – PRO TAPER MICROBARS – COBRA KING BEND
2 TCMU0021 GRIPS (SET OF TWO) – MICROGRIPS – RED / GRAY FEW
3 FAMU0016 THROTTLE ASSEMBLY – PRO TAPER COBRA
3A FAMU0015 TUBE ASSEMBLY – THROTTLE – 2 PIECE PRO TAPER MICRO
3B HCBC0525 M5 X 25 SHCS – THROTTLE ASSEMBLY
3C FCMU0041 STOP RING – MICRO BAR THROTTLE
4 FCPW0004 CABLE COVER
5 FCMU0021 THROTTLE COVER
6 FCMU0019 THROTTLE CABLE
6A HCNJ0801 NUT – 8MM JAM
7 BAKG0003 BRAKE ASSEMBLY FRONT
8 FCMU0033 KILL SWITCH ASSEMBLY
9 HCBC0806 M8X30mm SOCKET HEAD CAP SCREW (4 REQ’D)
10 HCBC1001 M10X45mm SOCKET HEAD CAP SCREW (2 REQ’D)
11 TKMU0404BLK BAR MOUNT KIT, SHORT (1 REQ’D) STANDARD
11A TKMU0403 BAR MOUNT KIT, TALL (1 REQ’D)
12 HCNL1001 M10 LOCK NUT
ACCESSORY BCKG0023 ALLOY BRAKE LEVER W/BALL
ACCESSORY BCKG0024 BRAKE PERCH ASSY W/LEVER & BALL
ACCESSORY MCMUAM11 GRIP DONUT – PAIR – PRO TAPER MICRO BAR
