19
Parts – Airbox & Inlet System
Air Box
REF # PART # DESCRIPTION
RCMU0018 CARBURETOR
1 TCCS0002 AIRBOX
2 HCSP0004 SCREW – PLASCREW - ALUMINUM
3 RCCS0016 AIR FILTER
4 RCKG0503 RETAINER – AIR FILTER
5 TCC60008 MUDFLAP
6 MCKGHO03 HOSE CLAMP – AIRBOX TO BOOT
7 RCKG0505 AIR BOOT
8 MCKGHO01 HOSE CLAMP – BOOT TO CARB
9 MCKGHO04 HOSE CLAMP – CARB TO MANIFOLD
10 RCMU0036 INLET MANIFOLD – 2016.5
11 ECMU0246 REED CAGE ASSEMBLY WITH REEDS VFORCE
12 ZCCS0001 GASKET – REEDS TO ENGINE
13 HCBC0603 M6X30mm SOCKET HEAD CAP SCREW
14 HCWF0601 6mm FLAT WASHER
15 RCCM1301 VELOCITY STACK (SCREWS ONTO CARB)
16 ECCS0030 REED REPLACEMENT KIT
