Parts – Engine – Water Pump

Engine – Ignition and Water Pump

REF # PART # DESCRIPTION

1 EKMU0021 WATER PUMP KIT

2 ECMU0265 SHAFT, WATER PUMP

3 ECKG0072 BEARING, WATER PUMP

4 ECKG0074 SEAL, WATER PUMP SHAFT

5 ECKG0073 IMPELLER, WATER PUMP (ALUMINUM)

6 HCBB0512 M5X12mm BUTTON HEAD

7 ECMU0167 BEARING – WATER PUMP BIG

8 EKMU0035 KIT – PULLEYS, SPACER & BELT RETAINER, FWE 2016.5

9 HCBS0009 SHOULDER BOLT

10 ECKG0170 WATER PUMP BELT

11 HCBC0408 M4X8mm SOCKET HEAD CAP SCREW (2 PLACES)

12 HCWF0401 4MM FLAT WASHER

13 ECMU0274 COVER – WATER PUMP

14 HCBC0412 M4 X 12 SHCS (2 REQ’D)

TOOL MCMUTL20 TOOL – WATER PUMP INSTALL - VENOM
