27
Engine – Clutch and Kick Starter
REF # PART # DESCRIPTION
1 CAMU0002 CLUTCH COMPLETE ASSY - 5GX
2 CAMU0009 3 SHOES & WASHER STACKS W BOLTS - 5GX
3 CCMU0005 CLUTCH ARBOR – 3 SIDED SPLINE
4 CAMU0014 WASHER STACKS - SET OF 3 - CLUTCH - 5GX
5 HCBT0001 BOLT - TORX - 5GX CLUTCH - M6 X 29
6 CCMU0008 SLEEVE - CLUTCH STACK 5GX
7 ECMU0018 CLUTCH NUT, SPECIAL
8 ECDC0030 BELLEVILLE LOCK WASHER
9 CCMU0007 CLUTCH BACKING SPACER
10 ECMU0120 CLUTCH BASKET WITH NEEDLE BEARING
11 ECMU0119 CLUTCH BEARING
12 ECMU0040 CLUTCH TO HUB SPACER(S) (0.030”, 0.76mm)
13 ECMU0132 FITTING - COOLANT
14 ECMU0307 NUT V3 CFD
15 HCCP0002 COTTER PIN 3/32 X 1 ½”
16 ECMU0308 BELLEVILLE SPRING V3 CFD
17 ECMU0306 SLIP HUB V3 CFD (2) REQ’D
18 ECMU0249 FRICTION MATERIAL V3 CFDTHICK (2 REQ’D)
19 ECMU0301 GEAR V3 CFD
20 ECMU0305 BUSHING V3 CFD 7mm
21 ECMU0272 OIL FILL PLUG, VENOM
22 ZCMUB014 O’RING – OIL FILL PLUG
23 HCFH0616 M6X16mm FLAT HEAD BOLT
24 ECMU0250 WASHER – KICK LEVER MOUNTING
25 EAMU0011 KICK LEVER
26 ECDC0078 SEAL - KICKSHAFT
28 HCBC0608 M6X55mm SHCS (2 REQ’D)
29 EAMU0018 CLUTCH COVER ASSEMBLY WITH SEAL AND PIN -2016
30 ZCMU0017 GASKET - CLUTCH COVER
31 ECMU0273 SPRING, KICKSTART
32 ECMUSP01 KICK START DOG SPRING (PAPER CLIP / ‘J’ SPRING)
33 ECMU0207 KICKSTART GEAR SMALL
34 ECMU0278 BRACKET – KICK SHAFT RETAINING
35 HCBC0508 M5 X 8mm SHCS (2 REQ’D)
36 ECMU0269 KICKSTART GEAR & SHAFT
KIT HKCP0001 10 PACK OF COTTER PINS (HCCP0002)
KIT EKMU0002 KICKSTART PIVOT KIT SPRING-BALL-SCREW
KIT HKAM0022 CLUTCH SHIM HARDEWARE KIT
KIT EKMU0033 CFD RFRESH KIT W’ FRICTIONS, SPRING, BUSHING AND COTTER PINS
TOOL MCMUTL40 TOOL - CFD – CHECK STOP PIN - VENOM
TOOL MCMUTL18 TOOL – SPROCKET SOCKET – HIGH TORQUE
TOOL ECMU0078 TOOL – SOCKET - CLUTCH NUT – CX50
TOOL MCMUTL03 TOOL – PISTON STOP
TOOL MCMUTL70 TOOL – PULLER – CLUTCH AND FLYWHEEL – CX50
