Cobra CX50SR - Parts - Engine - Top End

29
Parts – Engine – Top End
Engine – Top End
REF # PART # DESCRIPTION
1 EKMU0015 CYLINDER KIT (INCLUDES STUDS, PISTON, RINGS, PIN & CLIPS)
2 ZCMU0102 BASE GASKET (0.20mm) THICK
2 ZCMU0103 BASE GASKET (0.30mm) THICK
2 ZCMU0104 BASE GASKET (0.40mm) THICK
2 ZCMU0105 BASE GASKET (0.50mm) THICK
2 ZCMU0106 BASE GASKET (0.60mm) THICK
2 ZCMU0107 BASE GASKET (0.70mm) THICK
2 ZCMU0108 BASE GASKET (0.80mm) THICK
3 ECMU0060A PISTON KIT – ‘A’ SIZE (B, C, and D sizes available)
4 ECMU0077 BEARING, WRIST PIN
5 ECMU0155 PISTON RINGS (2 PER SET)
6 ECMUSR00 SNAP RING FOR PISTON (2 REQ'D)
7 ECKG0012 WRIST PIN
8 ZCMUOR07 O-RING, EXHAUST FLANGE
9 ECMU0262 EXHAUST FLANGE
10 ZCMOTE11 O-RINGS – PIPE TO FLANGE (2 REQ’D)
11 HCBC0612 M6X12, EXHAUST FLANGE SCREW (2 REQ'D)
12 HCNF0601 6MM FLANGE NUT (5 REQ’D)
13 ECC60149 CYLINDER HEAD OUTER
14 ZCC60009 O-RING, CYLINDER HEAD LARGE
15 ZCMUOR23 O-RING CYLINDER HEAD SMALL
16 ECMU0279 CYLINDER HEAD, INSERT, 2017
17 ZCMUOR05 O-RING CYLINDER HEAD MEDIUM - YELLOW
18 ZCMUOR03 O-RING CYLINDER STUD (5 REQ'D)
19 ECC60107 6MM STUD (5 REQ’D)
20 HCNF0801 8MM FLANGE NUT (4 REQ’D)
21 ECC60109 STUD, CYLINDER 8mm (4 REQ’D)
22 ECMU0010I SPARK PLUG, IRIDIUM AUTOLITE, XS61
TOOL MCMUTL03 TOOL-PISTON STOP
ACCESSORY
ZKMUOR13 TOP END O-RING KIT
