33
Front Forks and Triple Clamp
REF # PART # DESCRIPTION
1 KACS2016 FORK COMPLETE, BRAKE & NON-BRAKE SIDE
2 KCMU0011 FORK GUARD SET
3 TCC60019 WASHER FORK GUARD (4 REQ’D)
4 HCBC0601 M6X16mm, SOCKET HEAD CAP SCREW (4 REQ’D)
5 BCC60015 BRAKELINE CLAMP
6 HCBC0612 M6X12mm, SOCKET HEAD CAP SCREW (2 REQ’D)
7 HCNL0601 M6 LOCKNUT (2 REQ’D)
8 FACS0007 TRIPLE CLAMP BOTTOM ASSY, (CLAMP & STEM)
9 FCCS0053 TRIPLE CLAMP TOP
10 HCNJ0102 STEERING HEAD JAM NUT (2 REQ’D)
11 FCMU0151 CAP – STEERING STEM
12 HCBC0806 M8X30 SOCKET HEAD CAP SCREW (4 REQ’D)
13 TKMU0404 BAR MOUNT KIT, SHORT (1 REQ’D) STANDARD
13A TKMU0403 BAR MOUNT KIT, TALL
14 HCBC1001 M10X45mm SOCKET HEAD CAP SCREW (2 REQ’D)
15 HCNL1001 M10 LOCK NUT
16 FCMU1103 DUST COVER (1 REQ’D)
17 ZCMUOR35 O-RING – CLUTCH SLAVE & STEERING STEM (2 REQ’D)
18A FCMU0038 SPACER – TOP
18B FCMU0037 SPACER - BOTTOM
19 FCMU0039 SEAL (2 REQ’D)
20 FCMU0004 STEERING HEAD BEARING (2 REQ’D)
21 HCBC0603 M6X30mm SOCKET HEAD CAP SCREW (4 REQ’D)
22 HCBF0616 M6X16mm FLANGE HEAD BOLT (4 REQ’D)(FENDER MOUNTING)
23 HCBF0616 M6X16mm FLANGE HEAD BOLT (NUMBER PLATE MOUNTING)
24 HCBC0625 M6X25mm SOCKET HEAD CAP SCREW (4 REQ’D)
25 FCMU0011 STEERING HEAD RACE (2 REQ’D)
26 HCWS1015 SHIM WASHER – STEERING HEAD NUT
ACCESSORY
FKMU0006 KIT – STEERING STEM BEARINGS, RACES AND SEALS-2016-CUR
TOOL MCMUTL11 TOOL – SOCKET – JAM NUT – STEERING HEAD
TOOL MCMUTL44 TOOL – BEARING AND SEAL INSTALLER ASSY
