TN800 A-PNL-AUX96-3 Auxiliary Connector
MT-3/4 Radio Systems
TECHNICAL NOTES
Page 3 of 4
LMRSALES@CODANCOMMS.COM
CODANCOMMS.COMTECHNICAL NOTE:
TN800, REV 5-0-0, © Aug 2013
CANADA/US +1 250 382 8268 | TOLL FREE +1 800 664 4066
Table 2: Auxiliary Control Connector De nitions for Transmitter / Receiver Series
Connector Name Pin # MT-3 Module MT-4E Module
Tx A Bank Sel J6-1 TX A STANDBY TX A BANK A/B SEL
Tx B Bank Sel J6-8 TX B STANDBY TX B BANK A/B SEL
Rx A Bank Sel J6-7 RX A ISO COR K RX A BANK A/B SEL
Rx B Bank Sel J6-14 RX B ISO COR K RX B BANK A/B SEL
Tx A Sec/Clr J5-5 TX A SUBT I/P 2 TX A SEC/CLR I/P
Tx B Sec/Clr J5-13 TX B SUBT I/P 2 TX B SEC/CLR I/P
Rx A Sec/Clr J6-2 RX A AMP AUD RX A SEC/CLR O/P
Rx B Sec/Clr J6-9 RX B AMP AUD RX B SEC/CLR O/P
Rx A Mode J4-10 RX A PRIOR COR RX A A/D MODE O/P
Rx B Mode J4-14 RX B PRIOR COR RX B A/D MODE O/P
