Repeater Confi guration Jumpers
Repeater Confi guration Keying JU1 JU2 JU3
Repeater in A side of subrack RXA -> TXA Out Out Out
Repeater in B side of subrack RXB -> TXB In Out Out
Two independant repeaters RXA -> TXA Out In Out
in each side of subrack RXB -> TXB
* Drop-Link on A side RXA -> TXA In In Out
(Repeater A side with Link B side) RXA -> TXB
Set RXA priority for Simplex Links RXB -> TXA
* Drop-Link on B side RXA -> TXB Out Out In
(Repeater B side with Link A side) RXB -> TXA
Set RXB priority for Simplex Links RXB -> TXB
Crossband System (No Simplex) RXA -> TXB In Out In
RXB -> TXA
Crossband System with Simplex RXA -> TXB In In In
frequencies on A or B side RXB -> TXA
(First receiver has priority always)
* Drop-Repeating Link RXA -> TXA Out In In
(Repeater in A or B side with RXA -> TXB
repeating link in A or B side) RXB -> TXA
RXB -> TXB
Receiver Priority Jumper Settings
These jumpers are only used for the Drop-Link confi gurations noted with an * above. For Drop-Links with Simplex
links, set the receiver priority to the local repeater receiver.
Receiver Priority JU9 JU10 JU11
First receiver active has priority Out Out Out
RXA priority In Out Out
RXB priority Out In Out
