FILTERBREW & SERVING CONCEPT
65
EXPLODED VIEW
HVA\HVM
Spare parts list
POS. PCS Part No. Description
1 1
1304061 Lid plastic HVA
2
1 1031301 HVA lid
3
1 1304062 Top plastic HVA
4
1 160970 CQ sticker
5
1 1802120 Connection faucet short
6
1 120200-02 Faucet metal black top
7
1 1031641 Electronic unit PCB HVA
8
1 1603853 Membrane switch HVA
9
1 253207 Drip tray insert
10
1 1304063 Drip tray HVA
11
1 220221 High limit switch short with connect
12
1 1206589 Gasket tank
13
1 1205303 Sensor HVA tall(160mm)
14
1 1205302 Sensor short (55mm)
15
1 1505042 Inlet hose 3/4”-1/2”
16
1 1206604 Gasket DIA18mm x 9mm D2mm
17
1 1206603 Gasket DIA23.5mm x 15mm D3mm
18
1 2760094 Gasket set for inlet hose
19
1 120422 Air vent
20
2 1402150 Screw T20 M4x8mm
21
4 1401101-01 Nut M3
22
2 1461008 Spring washer M3
23
1 1605362 Double seal level sensor
24
1 1203527 Tank complete HVA
25
1 1206507 Fiber washer
26
1 1601311 Element 2200W/230V with SS nuts
27
1 1605361 Seal NTC
28
1 1206123 Non return valve
29
3 140330 Clamp 13.3mm
30
Sale in M 150501 Silicon hose 8X12mm
31
1 1403400 PP plug for drainage hose
32
1 1206581 Seal solid state
33
1 1604203/1604201 Solid state 25A
34
4 120320 Rubber feet V2
35
1 1402163 Screw T20 M4x8mm
36 1 1403401 Inlet valve plug with silicon seal
37 1 160801-04 Rocker switch single
38 1 160571 Emi fliter with AC socket
39 1 120624-01 Single valve 2.5L/min
40 1 711000
NTC thermistor belong
41 1 160565 Power cord european 16A250V
