Cognex DataMAN 262 X - Dataman 260 Series Imager Specifications; LED Wavelengths

Operating
Temperature
0ºC — +40ºC (+32ºF — +104ºF)
Storage
Temperature
-10ºC — +60ºC (+14ºF — +140ºF)
Maximum
Humidity
<95% (non-condensing)
Environmental IP65
Shock and
Vibration
IEC 60068-2-27: 1000 shocks, semi-sinusoidal, 11g, 10ms
IEC 60068-2-6: vibration test in each of the three main axis for 2 hours @ 10 Gs (10 to 500 Hz at
100m/s2 / 15mm)
LED Safety IEC 62471: Exempt risk group, no further labeling is required.
RS-232 RxD, TxD according to TIA/EIA-232-F
Codes
1-D barcodes: Codabar, Code 39, Code 128, and Code 93,Code 25, Interleaved 2 of 5, Pharma, GS1
DataBar, Postal, Code UPC/EAN/JAN, MSI
2-D barcodes: Data Matrix
TM
(IDMax and IDQuick: ECC 0, 50, 80, 100, 140, and 200) QR Code and
microQR Code, RSS/CS, PDF 417, MicroPDF 417, AztecCode, DotCode, MaxiCode
Discrete I/O
operating
Limits
HS Output 0, 1
, 2, 3
I
MAX
@ 24 VDC
50
mA
R
MAX
@ 12 VDC
150
Ω
@ 24 VDC
470
Ω
Input 0 (Trigger) V
IH
±15 — ±25 V
Input 1 V
IL
0 — ±5 V
I
TYP
@ 12 VDC
2.0
mA
@ 24 VDC
4.2
mA
Power Supply
Requirements
Options:
l PoE powered: Class 1 PoE supply, maximum 3.84 W
l External power supply (no PoE): +24 VDC +/- 10% (1 A maximum, 5 W average)
Supplied by LPS or NEC class 2 only
Power
Consumption
<3.84 W (PoE Class 1)
<5 W (average, externally powered at +24 V)
Ethernet
Speed
10/100
Duplex Mode Full duplex or half duplex
DataMan 260 Series Imager Specifications
Specification
DataMan 260
Imager
DataMan 262
Imager
Image Sensor 1/3 inch CMOS 1/3 inch CMOS
Image Sensor
Properties
4.51 mm x 2.88 mm (W x H), 6.0 μm square
pixels
4.8 mm x 3.6 mm (W x H), 3.75 μm square
pixels
Image Resolution
(pixels)
752 x 480 1280 x 960
Lens Type
S-mount 6.2 mm F:5 (with optional liquid lens) with IR blocking filter
S-mount 16 mm F:7 (with optional liquid lens) with IR blocking filter
LED Wavelengths
The following table shows LED types and the related wavelengths:
