CTSTORE reset Calibration table reset (COMMAND)
Description
Clears all in-memory calibration table entries. Sets “no calibration” text entry into the
info setting.
Returns None
CTSTORE on | off Calibration table use (COMMAND)
Description Calibration table use enable (on) or do not use (off)
Returns None
CTSTORE info arg1 Calibration table set information (COMMAND)
Description Sets the calibration table information to arg1. 128x characters max.
Returns None
CTSTORE? Calibration table in use query (COMMAND)
Description
Returns calibration table in use status
Returns
0 calibration table not in use
1 calibration table in use
CTSTORE? info Calibration table information (QUERY)
Description Return the calibration table description information text
Returns
DATE=12/20/2020_9:55:11_AM,SN=1711XXXX,VNA=E8362C-MY43021160,
MARKER_F=02777777777
CTSTOREM Calibration Table Store Multiple (QUERY)
Description
CTSTOREM stores multiple entries into the Calibration Table starting with the rst entry at the specied
index. The Calibration Table is stored in non-volatile memory.
Syntax
CTSTOREM index [ arg1, arg2, arg3, arg4 … arg20 ]
index is the starting index in the Calibration Table to store the following entries. There are 1251 entries (0
thru 1250) for each 0.5 ps step from the entire range of 0 to 625.0 ps.
arg1, arg2, … table entries …
Note: Each entry in the table is the integer amount of femtoseconds (fs) of calibration compensation
required at each step in the entire range of the trombone. Each entry (or compensation amount) is
subtracted from the actual performance of the uncalibrated trombone to offer the corrected calibrated
position of delay.
Maximum of 20 arguments can be specied per line.
Example CTSTOREM 100 1005, -2002, -0310, 0088 …
Returns None
