compacta_g - 02_05
1.2.1 Machine removal from pallet
l Remove the four screw fastening both bars between pallet and machine.
l Descent of machine from skid must be controlled by TWO people, one standing by machine
rear and the other by frontside
CAUTION
While moving the machine, mind it does not run too fast or it does not stop suddenly
against the floor, as in both cases it might overturn thus bringing about damage to people
and/or things all around.
CAUTION!
Removal from pallet must be carried out from TWO people properly instructed in material
handling. Remove machine from pallet only after carefully reading following instructions.
l Place the wooden skid the machine is equipped with, in relation to the machine rear.
l Push the machine from its rear till both bars drop, thence withdraw them sideaway.
