- 39 -
6.4 BEATER DISASSEMBLY
l Disassemble the beater 21 by withdrawing it from the cylinder, remove the scraper blades
431, the stuffing box 28 and beater plastic plugs 85.
CAUTION
Handle with care, as a fall to the ground might damage the beater.
6.4.1 Stuffing box checking
When removing the stuffing box, check whether its shows defects. If not, after washing and
greasing the stuffing box, you can use it again.
If, on the contrary, you find ice cream rests in the drip drawer 27 , you would be better to
change it since, most problably, it is worn out and consequently leaks.
The spare stuffing box is to be found in the spare parts kit (see section "Maintenance").
CAUTION!
Clean with sanitizers at the end of every working day.
27
431
21
85
28
