2. GENERAL DATA
2.1 GENERAL INFORMATION
2.1.1 Manufacturer's identification data
The machine has a data plate carrying manufactuer's data, machine type and identification
number given when it is manufactured.
2.1.2 Information about service
All operations of routine maintenance are described in section "Maintenance" of this handbook;
any further operation requiring radical interventions on the machine must be agreed with the
manufacturer, who will also examine the possibility of a direct action on the spot.
2.1.3 Information to the user
l The manufacturer of the machine here described is at user's disposal for any explanation and
information about the machine operation.
l In case of need, the interlocutor is the distributor being present in user's country, or the
manufacturer if no distributor is in that market.
l Manufacturer's service department is at clients' disposal for any information about operation,
and requests of spare parts and service.
l The manufacturer reserves the right to carry out all machine changes deemed as opportune
without previous notice.
l Descriptions as well as pictures contained in this handbook are not binding.
l Reproduction rights are reserved to COLDELITE.
2.2 INFORMATION ABOUT THE MACHINE
2.2.1 General information
Floor standing machine for the production of ice cream, skim or fruit ice cream.
The machines are provided with an electronic control keyboard for the access to all functions.
Following are the main components of COMPACTA:
l Top cylinder for heating and mixing
l Lower cylinder for production and execution of production cycles
l Electronic control panel divided by heating and production sides
l Flexible shower-head for cleaning the cylinders
l Lids for ice cream filling in heating and freezing cylinders
l Levers for ice cream dispense and transfer from top cylinder to lower cylinder
l Front lids with safety devices for cylinders opening
l Wheels for easy moving
A= Serial number
B=Machine type
C= Voltage
D= Fuse Current
E= Gas type and
weight
F= Condensation
W=Water
G= Frequency
A
BC
D
E
F G
