Bottom View
M8 Nuts
M8 x 20mm Bolts
Large M8 Washers
M8 Nuts
Large M8
Washers
Torque bolts 15 ft/lbs.
REAR FENDER INSTALLATION
M8 x 20 Bolts
1. Attach Rear fender with M8 x
20 bolts, large M8 washers and
M8 nuts.
4

Table of Contents

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Coleman BT200X and is the answer not in the manual?

Coleman BT200X Specifications

General IconGeneral
FrameSteel
Fuel SystemCarburetor
Final DriveChain
Fuel Capacity0.95 Gallons
Front SuspensionTelescopic fork
Front BrakeDisc
Front Tire70/100-19
Rear Tire90/100-16
Engine TypeSingle Cylinder, 4-Stroke, Air Cooled
Weight121 kg (267 lbs)
Weight Capacity150 kg (330 lbs)
Wheelbase1, 270 mm (50 inches)
