Coleman BT200X User Manual

OIL AND FUEL
Engine Oil
1
Fuel level
Filler neck
FUEL
Fill with gasoline up to the bottom of the
ller neck.
Fill level
Mini bike is shipped without
engine oil, fill with
SAE 10W-30 Motor Oil.
Refer to owner's manual for
correct amount and grade of
engine oil.
Caution: Do not over or under ll
with engine oil
9
Never use leaded gasoline in this product.
It could affect the engine’s emissions and
damage the engine.
Mini Bike requires clean unleaded regular
gasoline with a minimum octane rating of
86 or higher.

Coleman BT200X Specifications

General

Frame	Steel
Fuel System	Carburetor
Final Drive	Chain
Fuel Capacity	0.95 Gallons
Front Suspension	Telescopic fork
Front Brake	Disc
Front Tire	70/100-19
Rear Tire	90/100-16
Engine Type	Single Cylinder, 4-Stroke, Air Cooled
Weight	121 kg (267 lbs)
Weight Capacity	150 kg (330 lbs)
Wheelbase	1, 270 mm (50 inches)
