TO IDLE WHEN RELEASED.
FREE MOVEMENT AND SNAP BACK
THROTTLE CABLE SHOULD HAVE
BEFORE STARTING ENGINE, THE
ALWAYS CHECK THROTTLE CABLE
! WARNING
SECURE WIRES AND CABLES
INSTALL CLUTCH COVER
2. Secure wires and cables to frame
using the Zip ties provided.
Zip Ties
1. Make sure the On/Off Switch
wire, throttle cable and brake
cable are not kinked and have free
movement when the handle bars
are turned from left to right.
!
WARNING
8
Zip Ties

Table of Contents

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Coleman BT200X and is the answer not in the manual?

Coleman BT200X Specifications

General IconGeneral
FrameSteel
Fuel SystemCarburetor
Final DriveChain
Fuel Capacity0.95 Gallons
Front SuspensionTelescopic fork
Front BrakeDisc
Front Tire70/100-19
Rear Tire90/100-16
Engine TypeSingle Cylinder, 4-Stroke, Air Cooled
Weight121 kg (267 lbs)
Weight Capacity150 kg (330 lbs)
Wheelbase1, 270 mm (50 inches)
