User Manual
3
4. Cycle start push-button
After having correctly positioned the document and the relevant cover, press this push-button to start
the welding/trimming cycle. During the parameter setting stage (see section 6.3), using this push-
button you can select the desired option.
+ To start the welding/trimming cycle, the push-button must be pressed only once. In other
words, after having pressed the cycle start push-button, neither press it again, nor press the
cycle start pedal until the operation ends.
5. Cycle start Pedal
It has the same function of the cycle start push-button and it allows you to carry out the covering
cycle with hands free. After having correctly positioned the document and the cover, press the pedal
to start the welding/trimming cycle.
+ To start the welding/trimming cycle, the pedal must be pressed only once. In other words,
after having pressed the cycle start pedal, neither press it again nor press the cycle start push-
button until the operation ends.
6. Power socket
It allows the connection of the unit’s power cable. See the “Installation and Connection” section for
further details.
7. Main switch
It turns the unit on/off.
8. Pedal connection socket
It allows the connection of the cycle start pedal (5).
1.2 Symbols used
Notes, warnings or suggestions for the user.
Prescriptions for the user safety and the equipment integrity
Obligation to dispose of the environmental impact material in compliance with the
regulations in force
Operations executable by means of a simple, yet necessary visual check
