6.3 Table of faults
Fault
Possible cause Remedy
To be
performed by
Machine cannot be
switched on
No mains power Check power supply Operator
Defective device fuse Replace fuse Electrician or
manufacturer
Fault at electrical system Establish and remedy fault Electrician or
manufacturer
Machine operates,
but does not work
Owner-side protective
equipment blocked or faulty
Determine the cause and
remedy the error. After this,
ensure that no persons are in
the danger zone and confirm
the interruption.
By specialist
authorized by
operating
company
Fault in the safety chain of the
entire plant
Device does not
label or labels
incorrectly
Incorrect dispenser settings Check settings: pre-
dispensing, pressure roller,
incremental encoder, label and
goods suppression, READY
and LOCK inputs, paper brake,
label sensor
Operator
Error message at
operator panel
Remedy the displayed error Take action as directed by
error message
Operator
Label supply?
Carrier paper?
Sensors?
Incremental encoder?
Paper brake?
Pressure roller open?
With every label roll change,
remove the carrier paper from
the rewinder
Check the loop pendulum
position (turn off!)
Air / vacuum? Check air pressure / vacuum Specialist
COLLAMAT AG
OFFLINE
Message at operator panel Check connection control unit
to operator panel
Specialist
Master controller error
Firmware problem
PIC offline Status message at operator
panel
Slave controller error
Firmware problem
Specialist
Poor label position Unsuitable label paper Insert new label roll Operator
Label guide Check null edge, parallel -
paper course?
Operator
Drive motor turns
off (display on
operator panel)
Motor overloaded Determine the cause of the
overloading and remedy it, e.g.
high friction of the label strip.
Specialist
