2.2 The traction unit
Description
The traction unit system is either attached directly using a
clamping piece connection or using a module rail on an adjustable
unit.
The corresponding peripheral devices are installed on the module
rail and / or on one of the many flanges on the housing.
All mechanical parts are surface-treated against corrosion.
The traction cylinder of the system is treated with a special coating
for permanent, slip-free drive transmission to the carrier paper.
The braking force of the label strip break is infinitely adjustable.
The traction cylinder can be easily turned by hand when the
dispenser is powered down (power OFF) to simplify setup of the
dispenser.
The rewinder drive system can be easily turned by hand to simplify
setup of the dispenser.
The pressure roller that holds the carrier paper on the traction
cylinder can be easily lifted (opened) using a turning knob for easy
setup of the dispenser.
When the pressure roller is open, this is displayed on the operator
panel (TUO - Error - corresponding warning message).
Uninterruptible labeling can be setup by installing the so called
Nonstop-Cabling-Set (two Collamat S are used – only one
incremental encoder will be used in speed mode: TACHO).
Several helpful options are available to increase the performance
and comfort of a Collamat S. These are the most important
options:
- Electrical rewinder unit (ERW)
- Indicator light column (red-green-orange) (SIG)
- Label volume (empty) observation (LLO)
- Rewinder volume (full) observation (RWF)
- Connection-Box (CBO)
- Connection-Module (CMO)
- Incremental-Encoder (TACHO)
- Magnet Flap Adapter (MFA)
- External Operator Panel (EOP)
- Double Dancer Rewinder
- Double Dancer Unwinder
- Lying Down Set
- Ø400mm Unwinder Disks
- div. clamps, modular rails adjusting units
- div. stands
- etc.
