Function Keys
OK: Enter key
ESC: Exit the current menu or operation
BRIGHT: Brightness adjustment. Press the key and rotate the knob to adjust
screen brightness, and then press the knob/OK to confirm the current
brightness.
BLACK: Blackout
Selection Keys
HDMI/DVI1/DVI2: Video source selection
PART: Turn on the cropping function. Press the key and the image will be
cropped according to the cropping setting in the software. You can cancel
cropping by pressing the key for a second time.
Power Switch
Switch on or off the power supply
Power Connector
AC 100-240V，50/60Hz
USB IN/OUT
USB IN, connecting to PC for debugging
USB OUT, for cascading with the next controller
HDMI/DVI1/DVI2
Support resolution up to 1920×1200@60Hz
Gigabit Ethernet Outputs
X2s—2×RJ45 Gigabit Ethernet ports
X4s—4×RJ45 Gigabit Ethernet ports
Operating Temperature: -20℃~60℃
Anti-static design, low EMI radiation
