SYMBOLOGY USED ON THE MACHINE
SYMBOLOGY USED ON THE MACHINESYMBOLOGY USED ON THE MACHINE
SYMBOLOGY USED ON THE MACHINE
Cock symbol
Indicates the cock lever
Indicates the cock open signal lamp
Squeegee base lift/lower symbol
Indicates the base lift lever
Brush symbol
Indicates the brush motor switch
Suction motor symbol
Indicates the suction motor switch
Squeegee lift/lower symbol
Indicates the squeegee lift lever
Battery symbol
Indicator of the battery charge level
Indicates also the position of the cock level (switched off = cock closed, switched on = opened cock)
Indicates the detergent solution maximum temperature
It is placed closed to the solution tank inlet opening.
Indicated the recovery tank outlet pipe
