12
MACHINE PREPARATION
ASSEMBLING THE BRUSH ABILA 17-20
1. Raise the base by means of the appropriate pedal.
2. With the base up, position the brush in line with the coupling on the machine.
3. Lower the base by means of the pedal.
4. Using the "man present" lever (6), the brush is automatically hooked up.
6
5. To alter the machine forwards speed, use the knob shown in the figure.
