SYMBOLS USED ON THE MACHINE
Tap symbol
Indicates the tap lever
Indicates the tap indicator light ON
Symbol denoting base rise/fall
Indicates the base rise/fall lever
Brush symbol
Indicates the brush motor switch
Symbol denoting suction motor
Indicates the suction motor switch
Symbol denoting squeegee rise/fall
Indicates the squeegee lever
Battery symbol
Battery charge level indicator
Also indicates the position of the tap (off = tap closed, on = tap open)
Indicates the maximum temperature of the detergent solution
Located near the solution tank inlet
Indicates the recovery tank drainage tube
