WEEKLY MAINTENANCE
CLEANING THE SQUEEGEE TUBE
Every week, or whenever suction seems to be unsatisfactory, check the squeegee tube
is not obstructed.
To clean it, proceed as follows:
1. Unthread the tube from the sleeve on the squeegee
2. Remove the other end from the recovery tank
3. Wash the inside of the tube with a water jet introduced from the side where it is
connected to the tank
4. To reassemble the tube, repeat the above-mentioned operations in the reverse
order
WARNING! Do not wash the tube running between the suction unit and
the suction cap
CLEANING THE SOLUTION TANK
1. Loosen the solution tank cap
2. Rinse with a jet of water
3. Remove the drainage cap (1) and empty the tank
WARNING! This operation must be carried out wearing gloves to protect
against contact with dangerous solutions
1
REPLACING THE SQUEEGEE RUBBERS
Check the state of wear and tear of the squeegee rubbers and, if necessary, replace
them.
To replace them you must:
1. Unthread the squeegee tube from the sleeve
2. Remove the pin from the small column
3. Disassemble the squeegee from its support
4. Loosen, by two turns, the knobs (1) blocking the rubber-pressing blades, and
Remove them
5. Replace the rubbers
To reassemble the squeegee, repeat the above-mentioned operations in the reverse
order
