7
MACHINE PREPARATION
HANDLING THE PACKED MACHINE
The machine is contained in specific packaging with a pallet for the
handling with fork trucks. It is not possible to place more than two
packages on top of each other.
The total weight is: -Abila 42: 136 kg
-Abila 52: 138 kg
-Abila 17: 136 kg
-Abila 20: 138 kg
The overall dimensions of the package are:
A: 1260 mm
B: 660 mm
C: 1230 mm
A
C
B
HOW TO UNPACK THE MACHINE
1. Remove the outer packaging
2. The machine is fixed to the pallet by means of a strap
3. Remove the strap
4. Use a chute to get the machine down from the pallet, pushing it
backwards. Avoid violent blows to the base
5. Keep the pallet for any future transport needs.
