17
DAILY MAINTENANCE
DISASSEMBLING THE BRUSHES ABILA 42 52
1. Raise the base by means of the pedal (downwards).
2. Disconnect the brush motor from the power supply, via the switch (1)
WARNING! Carrying out the brush disassembly operations with the
power supply connected may cause injuries to the hands.
1
3. With the base up, rotate the brush until it comes out of the brush-holder plate seat,
as shown in the figure. The figure shows the rotation direction to release the right-hand
brush; for the left-hand one, rotate in the opposite direction
WARNING! During this operation, check there are no people or objects
near the brush.
DISASSEMBLING THE BRUSH ABILA 17-20
1. Raise the base by means of the pedal (downwards).
2. With the base up, use the "man present" lever to automatically release the brush
CLEANING THE SOLUTION DRAINAGE FILTER
1. Loosen the filter on the lower rear side of the machine
2. Rinse with a jet of water
3. Reassemble all the elements
WARNING! During this operation, check there are no people or objects
near the brush
