COMAC VERSA 65BT - Brush Control and Maintenance (Antea B); Brush Control and Maintenance (Antea Bt)

50
MAINTENANCE
BRUSH CONTROL AND MAINTENANCE (ANTEA B)
Careful cleaning of the brush guarantees better cleaning of the oor
as well as a longer brush head gearmotor lifespan. To clean the
brush, proceed as follows:
1. Take the device to the dedicated maintenance area.
2. Raise the brush head unit off the oor and press the brush head
control pedal (1) on the rear of the device (Fig.1).
ATTENTION: do not lift the brush head unit completely.
3. Deactivate the vacuum motor by pressing the vacuum motor
command switch (2) on the control panel (Fig.2).
4. Press the dead man's levers (3) repeatedly three times (over the
span of one minute) (Fig.3).
5. Clean the brush under running water to remove any impurities
from its bristles. Check that the bristles are not worn; in the event
of excessive wear, replace the brush (the bristles should be at
least 10 mm long). Read “ASSEMBLING THE BRUSH” to replace
the brush.
ATTENTION: the place designated for this operation must
comply with current environmental protection regulations.
6. Reassemble the splash guard (read “ASSEMBLING THE BRUSH
HEAD SPLASH GUARD”).
BRUSH CONTROL AND MAINTENANCE (ANTEA BT)
Careful cleaning of the brush guarantees better cleaning of the oor
as well as a longer brush head gearmotor lifespan. To clean the
brush, proceed as follows:
1. Take the device to the dedicated maintenance area.
2. Raise the brush head unit off the oor and press the brush head
control pedal (1) on the rear of the device (Fig.1).
ATTENTION: do not lift the brush head unit completely.
3. Press the “BRUSH UNCOUPLING” button (2) on the control
panel (Fig.2).
ATTENTION: as soon as the “BRUSH UNCOUPLING” button
(2) on the control panel is pressed (Fig.2), the control display
will show the “CONFIRM UNCOUPLING?” screen (Fig.3).
4. Press the “BRUSH UNCOUPLING” button (2) again to conrm.
5. Clean the brush under running water to remove any impurities
from its bristles. Check that the bristles are not worn; in the event
of excessive wear, replace the brush (the bristles should be at
least 10 mm long). Read “ASSEMBLING THE BRUSH” to replace
the brush.
ATTENTION: these operations must be carried out using
protective gloves to avoid any possible contact with the edges
or tips of metal objects.
ATTENTION: the place designated for this operation must
comply with current environmental protection regulations.
