COMAC VERSA 65BT - Technical Data (Antea)

8
9
TECHNICAL DATA (ANTEA) U/M
ANTEA
50 B
ANTEA
50 BT
ANTEA 50
BTS
ANTEA 50
BTO
Rated power of the device W 920 1100 1200 1000
Working width mm 508 508 500 508
Working capacity up to m
2
/h 1250 1780 1750 1780
Maximum gradient with full load % 2 10 10 10
Standard squeegee width mm 700 700 700 700
Disc brush (number / diameter) No. / Ø mm 1 / 508 1 / 508 - -
Disc brush rotations rpm 140 140 - -
Brush head motor (Nominal power rating / Voltage) W / V 500 / 24 500 / 24 600 / 24 400 / 24
Cylindrical brush (number / (diameter - length)) No. / (Ø mm - mm) - -
2 / (110 -
500)
-
Cylindrical brushes rpm rpm - - 700 -
Rectangular pad (number / (width / depth)) No. / (mm - mm) - - -
1 / (508 /
355)
Discoid pad (number / (diameter) No. / Ø mm - - - -
Orbital revolutions rpm - - - 2300
Maximum weight exerted upon the brush head unit kg 23 23 25 25
Front wheel [number / (diameter / width)] no. / (Ø mm / mm) 2 / (175-60) 2 / (175-60) 2 / (175-60) 2 / (175-60)
Traction motor (Nominal power rating / Voltage) W / V - 180 180 180
Maximum forward speed Km/h - 3.5 3.5 3.5
Maximum reverse speed Km/h - 2.2 2.2 2.2
Vacuum motor (Nominal power rating / Voltage) W / V 420 / 24 420 / 24 420 / 24 420 / 24
Suction vacuum (hole Ø 0 measured at the motor) mmH
2
O 1240 1240 1240 1240
Solution tank capacity l 40 40 40 40
Recovery tank capacity l 60 60 60 60
Detergent tank capacity (versions with CDS) l - 3 3 3
Appliance length mm 1177 1177 1156 1071
Appliance height mm 992 1009 1009 1009
Appliance width (without squeegee) mm 591 591 612 591
Device width (with squeegee) mm 700 700 700 700
Battery compartment dimensions (Height - Width -
Length)
mm
285 - 350
- 355
285 - 350
- 355
285 - 350
- 355
285 - 350
- 355
Voltage and nominal capacity of the recommended
battery
V/Ah 12 / 112 12 / 112 12 / 112 12 / 112
Device weight (with tanks empty and without batteries) kg 80 87 90 89
Individual battery weight kg 38 38 38 38
Device transport weight (device + batteries) kg 156 163 166 165
Gross weight of the device ready for use kg 196 203 206 205
Sound pressure level (ISO 11201) - L pA dB (A) 66 66 <70 66
Uncertainty KpA dB (A) 1.5 1.5 1.5 1.5
Hand vibration level (ISO 5349) m/s2 <2.5 <2.5 <2.5 <2.5
Vibration measurement uncertainty 1.5% 1.5% 1.5% 1.5%
