IGS-NT-BC, SW Version 1.2.0, ©ComAp – January 2019
IGS-NT-BC-1.2.0 Reference Guide.PDF
As soon as the phase angle difference stays within the window adjusted by Phase
window and the voltage difference stays in the Voltage window, both for period
Dwell time, the circuit breaker closing command is issued.
NOTE:
See the chapter Regulation loops overview for general information about
regulation loops and their adjustment.
This setpoint adjusts the end point of the gen-set unloading ramp, i.e. power level
at which the GCB is opened. If this level is not reached within time period adjusted
by setpoint BCB open del the GCB is then opened regardless of the gen-set
power.
NOTE:
The speed of the ramp is adjusted by the setpoint Load ramp in subordinated gen-
sets.
This setpoint adjusts the maximum duration of the gen-set unloading ramp. If the
end point of the ramp (BCB open level) is not reached within time period adjusted
by this setpoint the GCB is then opened regardless of the gen-set power.
NOTE:
The speed of the ramp is adjusted by the setpoint Load ramp in subordinated gen-
sets.
1 .. 1800, NO TIMEOUT [s]
This setpoint adjusts the maximum duration of forward or reverse synchronization.
If the synchronizing is not successful within this period of time, the Sync Timeout
or RevSyncTimeout alarm will be issued.
NOTE:
If the synchronizing is not successful within 1/10 of the Sync timeout or 60s (if
Sync timeout <600s) the synchronization process is automatically restarted again,
