Page #155 background image
IGS-NT-BC, SW Version 1.2.0, ©ComAp January 2019
IGS-NT-BC-1.2.0 Reference Guide.PDF
155
Value: Pwr factor L3
Group
Bank values
Units
-
Related FW
3.0
Description
Generator power factor in phase L3.
Value: Load char L3
Group
Bank values
Units
-
Related FW
3.0
Description
Character of the generator load in the L3 phase. "L" means inductive load, "C" is
capacitive and "R" is resistive load (power factor = 1).
Value: Bank PF
Group
Bank values
Units
Hz
Related FW
3.0
Description
Bank cos-phi factor.
NOTE:
The "cos-phi" factor is widely used instead of power factor for pure harmonic
waveforms, because a simplified method can be used for calculation of it's value.
However, if this simplified method is used for significantly distorted waveforms, it
may provide inaccurate results. This fact causes the controller "power factor"
value may be different from a value measured by another true-rms measurement
device if the waveform contains significant portion of higher harmonic frequencies.
Value: Bank Lchr
Group
Bank values
Units
Hz
Related FW
3.0
Description
Character of the bank load. "L" means inductive load, "C" is capacitive and "R" is
resistive load (power factor = 1).
Value: Bank freq
Group
Bank values
Units
Hz
Related FW
3.0
Description
Bank frequency. The frequency is measured in the phase L3.
Value: Bank V L1-N
Group
Bank values
