IGS-NT-BC, SW Version 1.2.0, ©ComAp January 2019
IGS-NT-BC-1.2.0 Reference Guide.PDF
156
Units
V
Related FW
3.0
Description
Bank voltage in phase L1.
NOTE:
The ratio between the voltage measured at the input terminals and the displayed
voltage is adjusted by the setpoint VT ratio.
Value: Bank V L2-N
Group
Bank values
Units
V
Related FW
3.0
Description
Bank voltage in phase L2.
NOTE:
The ratio between the voltage measured at the input terminals and the displayed
voltage is adjusted by the setpoint VT ratio.
Value: Bank V L3-N
Group
Bank values
Units
V
Related FW
3.0
Description
Bank voltage in phase L3.
NOTE:
The ratio between the voltage measured at the input terminals and the displayed
voltage is adjusted by the setpoint VT ratio.
Value: Bank V
Group
Bank values
Units
V
Related FW
3.0
Description
Bank voltage. Average from all three phases.
NOTE:
The ratio between the voltage measured at the input terminals and the displayed
voltage is adjusted by the setpoint VT ratio.
Value: Bank V L1-L2
Group
Bank values
Units
V
Related FW
3.0
Description
Bank voltage between phases L1 and L2.
