NOTE:
The ratio between the voltage measured at the input terminals and the displayed
voltage is adjusted by the setpoint VT ratio.
Value: Bank V L2-L3
Group
Bank values
Units
V
Related FW
3.0
Description
Bank voltage between phases L2 and L3.
NOTE:
The ratio between the voltage measured at the input terminals and the displayed
voltage is adjusted by the setpoint VT ratio.
Value: Bank V L3-L1
Group
Bank values
Units
V
Related FW
3.0
Description
Bank voltage between phases L3 and L1.
NOTE:
The ratio between the voltage measured at the input terminals and the displayed
voltage is adjusted by the setpoint VT ratio.
Value: Bank curr L1
Group
Bank values
Units
A
Related FW
3.0
Description
Bank current in phase L1.
NOTE:
The ratio between the current measured at the input terminals and the displayed
current is adjusted by the setpoints CT ratio prim and CT ratio sec.
Value: Bank curr L2
Group
Bank values
Units
A
Related FW
3.0
Description
Bank current in phase L2.
NOTE:
The ratio between the current measured at the input terminals and the displayed
current is adjusted by the setpoints CT ratio prim and CT ratio sec.
