ComAp IG-NTC GC User Manual

IGS-NT-BC, SW Version 1.2.0, ©ComAp – January 2019
IGS-NT-BC-1.2.0 Reference Guide.PDF
169
Value: AIN CU-2
Group
Analog CU
Units
configurable
Related FW
3.0
Description
This is the value of the analog input 2 of the controller. Analog inputs are fully
configurable so the name and units depend on configuration. In the default
configuration the input is used for water temperature measurement.
Value: AIN CU-3
Group
Analog CU
Units
configurable
Related FW
3.0
Description
This is the value of the analog input 3 of the controller. Analog inputs are fully
configurable so the name and units depend on configuration. In the default
configuration the input is used for fuel level measurement.
Value: AIN CU-4
Group
Analog CU
Units
configurable
Related FW
3.0
Description
This is the value of the analog input 4 of the controller. Analog inputs are fully
configurable so the name and units depend on configuration. In the default
configuration the input is used for fuel level measurement.
Group: Bin inputs CU
Value: BIN
Group
Bin inputs CU
Units
-
Related FW
3.0
Description
This is a bit array containing status of physical binary inputs of the controller. Bit0
represents BI1, bit1 represents BI2 etc..
NOTE:
All terminals display binary values in "human-readable" form - from left to right.
That means the bit 0 is displayed in the most left position. This is different from
common use in computer science, where binary values are displayed from right to
left.
NOTE:
Click on button with "..." to get a clear list of BI names with their corresponding
values.
