ComAp IG-NTC GC User Manual

IGS-NT-BC, SW Version 1.2.0, ©ComAp – January 2019
IGS-NT-BC-1.2.0 Reference Guide.PDF
170
Group: Bin outputs CU
Value: BOUT
Group
Bin outputs CU
Units
-
Related FW
3.0
Description
This is a bit array containing status of physical binary outputs of the controller. Bit0
represents BO1, bit1 represents BO2 etc..
NOTE:
All terminals display binary values in "human-readable" form - from left to right.
That means the bit 0 is displayed in the most left position. This is different from
common use in computer science, where binary values are displayed from right to
left.
NOTE:
Click on button with "..." to get a clear list of BI names with their corresponding
values.
Group: Log Bout
Value: LogBout 1
Group
Log bout
Units
-
Related FW
3.0
Description
This is a bit array containing status of logical binary outputs 1-16 of the controller.
Bit0 represents LBO1, bit1 represents LBO2 etc..
NOTE:
All terminals display binary values in "human-readable" form - from left to right.
That means the bit 0 is displayed in the most left position. This is different from
common use in computer science, where binary values are displayed from right to
left.
NOTE:
Click on button with "..." to get a clear list of BI names with their corresponding
values.
Value: LogBout 2
Group
Log bout
Units
-
Related FW
3.0
Description
This is a bit array containing status of logical binary outputs 17-32 of the
controller. Bit0 represents LBO17, bit1 represents LBO18 etc..
NOTE:
All terminals display binary values in "human-readable" form - from left to right.
That means the bit 0 is displayed in the most left position. This is different from
common use in computer science, where binary values are displayed from right to
left.
NOTE:
