Setpoint: Derated2 pwr
Group
Process control
Range [units]
0 .. 100 [%]
Related FW
3.0
Force value
possible
YES
Description
This setpoint is used for adjusting the final power level for the Power derating 2
function. The nominal power is not reduced below this setpoint even if the
respective analog input increases further.
See the chapter Power derating for details.
Setpoint: Synchro enable
Group
Process Control
Range [units]
NONE, FORWARD, REVERSE, BOTH [-]
Related FW
3.0
Force value
possible
YES
Description
The setpoint is used for enable/disable forward and reverse synchronization.
• NONE: No synchronizing is enabled.
• FORWARD: GCB synchronizing is enabled.
• REVERSE: MCB synchronizing is enabled.
• BOTH: GCB and MCB synchronizing are enabled.
NOTE:
Although synchronizing of the particular breaker is disabled the breaker can be
closed to a "dead" (voltage-free) bus.
NOTE:
See table with examples in the description of the setpoint MFStart enable.
Setpoint: #Neutral cont
Group
Process control
Range [units]
EACH, COMMON [-]
Related FW
3.0
Description
The setpoint is used for adjusting the behavior of the Neutral CB C/O output
according to actual site wiring.
The neutral contactor is used to connect the neutral wire (N) with the protective
wire (PE) in a TN-S system. This connection must exist in one moment at one
point of the circuit only.
The EACH option should be used if each gen-set has it's own neutral contactor.
Four-pole GCB must be used for this case.
