IGS-NT-BC, SW Version 1.2.0, ©ComAp – January 2019
IGS-NT-BC-1.2.0 Reference Guide.PDF
PRINCIPIAL SCHEME OF A SITE IF NEUTRAL CONT = COMMON
NOTE:
As there is always a connection between the N and PE wires at the mains side the
generator neutral contactors are always open when the mains breaker is closed.
This setpoint is used at redundant controller to specify the address of the related
main controller in CAN-based rendundant systems. Adjust this setpoint to 0 if the
controller is not used as redundant or if wired rendundancy system is used.
Group: Basic settings
Setpoint: Nomin current
This setpoint is used for adjusting the generator nominal current.
The nominal current is used as the basis (100%) for generator thermal-
overcurrent protection (2Inom del), and for short current protection (Ishort).
NOTE:
The setpoints CT ratio prim and CT ratio sec must be adjusted properly to obtain
