Inteli NT GeCon MINT, SW Version 1.4, ©ComAp – June 2007
IGS-NT-GeCon-MINT-1.4.PDF
35
VSHARING The power factor is equalized with other gen-sets according to the actual reactive
load.
SysBaseLdMode [ INTERNAL / EXTERNAL ] (FV)
This setpoint selects from where the System Base load value is read if ProcessControl:#SysLdCtrl PtM =
BASE LOAD and MCB is closed (parallel to mains operation):
Force value: Yes
INTERNAL
Requested System Base load value is read from ProcessControl:#SysBaseLoad.
EXTERNAL
Requested System Base load value is read from the analog input MLC:AnExSysBld.
It is expected that this signal be propagated via the Virtual periphery system from
one source controller. In that controller, a physical analog input (with external Base
load request signal) must be connected to AOUT virtual periphery module and this
signal is then propagated to all other controllers set to EXTERNAL mode.
Hint:
You should set only one controller in the logical control group to send the data to the CAN bus (= AOUT
virtual periphery source), otherwise the system will not work properly.
SysBasePFMode [ INTERNAL / EXTERNAL ] (FV)
This setpoint selects from where the System Base load value is read if ProcessControl:#SysPFCtrl PtM =
BASEPF and MCB is closed (parallel to mains operation):
INTERNAL
Requested System Power factor value is read from ProcessControl:#SysPwrFactor.
EXTERNAL
Requested System Power factor value is read from the analog input
MPF:AnExSysBPF. It is expected that this signal be propagated via the Virtual
periphery system from one source controller. In that controller, a physical analog
input (with external Base load request signal) must be connected to SHAOUT virtual
periphery module and this signal is then propagated to all other controllers set to
EXTERNAL mode.
Hint:
You should set only one controller in the logical control group to send the data to the CAN bus (= SHAOUT
virtual periphery source), otherwise the system will not work properly.
