Inteli NT GeCon MINT, SW Version 1.4, ©ComAp – June 2007
IGS-NT-GeCon-MINT-1.4.PDF
58
Step: 0,01 V
Range: SpeedGovLowLim to SpeedGovHiLim V
Force value: Yes
SpdGovPWM rate [ Hz ]
Pulse-Width Modulation rate of the Speed Regulator pulse output.
Step: 1 Hz
Range: 500 – 3000 Hz
Hint:
This adjusting can be used for some Cummins and CAT engines speed governor interfaces. We recommend
to keep the default setting (1200 Hz) for all other speed governor types (coming out through the analog
interface +/- 10V).
SpeedGovLowLim [ V ]
Low limit for voltage on analog output of Speed Regulator.
Step: 0,01 V
Range: -10,00 V – SpeedGovHiLim
SpeedGovHiLim [ V ]
High limit for voltage on analog output of Speed Regulator.
Step: 0,01 V
Range: SpeedGovLowLim - 10,00 V
TauSpeedActuat [ s ]
Time constant of the speed actuator connected to the binary Up/Down outputs. This is to match the reaction
of the controller’s regulator with the actual reaction time of the actuator.
Step: 0,1 s
Range: 1,0 - 300,0 s
Load ramp [ s ] (FV)
Increasing or decreasing load rate. In seconds / Nomin power.
Step: 1 s
Range: 0 – GCB open del s
Force value: Yes
RampStartLevel [ % ]
Value of initial load, on which starts the load ramping according to Load ramp setting.
Step: 1 %
Range: 0 – 100 %
Load gain [ % ]
Gain of power control loop.
Step: 0,1 %
Range: 0 – 200,0 %
Load int [ % ]
Relative integration factor of power control loop.
Step: 1 %
Range: 0 – 100 %
Hint
:
Load gain and Load int setpoints are active only when gen-set operates in parallel to the mains, when GCB
and MCB are closed. This is valid for both single and multiple applications.
LS gain [ % ]
Gain of load sharing control loop.
Step: 0,1 %
