14 Binary input functions
14.1 Virtual and physical modules
Number of I/O can be extended and project wiring can be reduced using the following extension and
virtual modules.
MODULE NAME
BIN
BOUT
AIN
AOUT
NOTE
NUMBER OF
MODULES
SUPPORTED BY
CONTROLLER
Controllers
IM-NT(C)-BB
controller
12
12
3
1
Controller I/O.
-
IM-NT controller
6
6
-
-
Controller I/O.
-
Extension modules
IGS-PTM
8
8
4
1
Standard I/O extension module.
4
IS-AIN8
-
-
8
-
Standard I/O extension module.
10
I-AOUT8
-
-
-
8
Standard I/O extension module.
4
IS-BIN16/8
16
8
-
-
Standard I/O extension module.
6
IGL-RA15
-
15
-
-
15 Green, Red, Yellow LED panel.
4
Inteli-AIN8
-
-
8+1
-
Standard I/O extension module. One
Frequency/Pulse input.
10
Inteli-AIN8TC
-
-
8
-
Standard I/O extension module
10
Inteli-IO8/8
8
8
-
2
Standard I/O extension module
12
Inteli-IO16/0
16
-
-
2
Standard I/O extension module
6
Virtual modules
VPIO
8
8
-
-
Virtual periphery I/O module.
4
SHBIN
8
-
-
-
SHared (virtual) Binary INput module
6
SHBOUT
-
8
-
-
SHared (virtual) Binary OUTput
module
6
