ComAp InteliGen User Manual

String Selection
Use
↑
or
↓
buttons to select the string from the list and press the Enter button.
String Edit
Use
↑
or
↓
buttons to select the character and
→
←
buttons for the next position and
press Enter button.
Actual setpoint value
Sum of the setpoints group
Actual position in characters list
Actual setpoints group
Cursor position - Arrow right
Cursor position - Arrow left
Numbers / lower case / upper case
Insert space / character
Remove space / character
Direct button to the last Metering screen
InteliVision 5, InteliVision 8 – Operator guide, ©ComAp – January 2014
IGS-NT Operator Guide 01-2014.pdf
15

ComAp InteliGen Specifications

General

Category	Control Systems
Manufacturer	ComAp
Synchronization	Yes
Load Sharing	Yes
PLC Functionality	Yes
Display	LCD
Communication	Ethernet
Operating Temperature	+70 °C
Power Supply	9-36 VDC
Remote Monitoring	Yes
Event Log	Yes
Tier Support	Tier 4
