InteliLite Global Guide
102
Events
specification
Protection
type
Description
Analog Input 2 Sd SD
Value measured on analog input 2 is </> than Analog Protection 2
Sd (page 245) setpoint.
Analog Input 3 Wrn WRN
Value measured on analog input 3 is </> than Analog Protection 3
Wrn (page 247) setpoint.
Analog Input 3 Sd SD
Value measured on analog input 3 is </> than Analog Protection 3
Sd (page 248) setpoint.
Analog Input 4 Wrn WRN
Value measured on analog input 4 is </> than Analog Protection 4
Wrn (page 250) setpoint.
Analog Input 4 Sd SD
Value measured on analog input 4 is </> than Analog Protection 4
Sd (page 251) setpoint.
Wrn Battery Voltage WRN
Battery voltage is out of limits given by Battery Undervoltage (page
220) and Battery Overvoltage (page 221) setpoints.
Binary input Configurable Warning/BOC/Shutdown alarms on the binary inputs.
Sd Battery Flat SD
If the controller switches off during starting sequence (STARTER
(PAGE 597) output is active) it doesn’t try to start again and activates
this protection (controller assumes bad battery condition).
Sd Start Fail SD Gen-set start failed. All crank attempts were tried without success.
Parameters Fail NONE
Wrong check-sum of parameters. Happens typically after
downloading new firmware or changing of the parameter. The
controller stays in INIT mode. Check all parameters, change value of
at least one parameter.
Sd Gen Lx >V
BOC Gen Lx <V
(where x=1,2,3)
SD
BOC
The generator voltage is out of limits given by Gen <V BOC and Gen
>V Sd setpoints.
BOC Gen V
Unbalance
BOC
The generator voltage is unbalanced more than the value of Voltage
Unbalance BOC (page 232) setpoint.
BOC Gen >,
<Frequency
BOC
The generator frequency is out of limits given by Generator
Overfrequency BOC (page 233) and Generator Underfrequency
BOC (page 234) setpoints.
BOC Current
Unbalance
BOC
The generator current is unbalanced more than the value of Current
Unbalance BOC (page 230) setpoint.
BOC Current IDMT BOC
Generator current exceeds the limit for IDMT protection given by
Nominal Current (page 176) and IDMT Overcurrent Delay (page
229) setpoints.
BOC Overload BOC
The load is greater than the value given by Overload BOC (page
227) setpoint.
Sd Earth Fault SD
This alarm is activated when Earth Fault value exceeds Earth Fault
Sd (page 387) limit for at least Earth Fault Delay (page 386) period.
Sd Overspeed SD
The protection comes active if the speed is greater than Overspeed
Sd (page 207) setpoint.
