– AMF20/25, SW version 2.2, ©ComAp – September 2014 53
IL-NT-AMF-2.2-Reference Guide.pdf
Stop Button
Binary input has the same function as Stop Button on the InteliLite front panel. It is active in MAN
Mode only.
Hint:
Changed function of Stop Button. After the first pressing from running state, there is a standard delay
and controller change state to cooling. After holding the button down for 2 seconds controller goes to
stop state. The same holds true for BI “Stop Button”.
FaultResButton
Binary input has the same function as Fault Reset button on the InteliLite front panel.
Hint:
This binary input FaultResButton must not be permantly activated. It would discard some controller
protections.
HornResButton
Binary input has the same function as Horn reset button on the InteliLite front panel.
GCB Button
Binary input has the same function as GCB button on the InteliLite front panel. It is active in MAN
mode only.
MCB Button
Binary input has the same function as MCB button on the InteliLite front panel. It is active in MAN
mode only.
MainsFailBlock
If the input is closed, the automatic start of the gen-set at Mains failure is blocked. In case of running
gen-set in AUT mode, timer ReturnDel is started and when it elapse GCB is opened, gen-set goes to
cooling procedure and stops. When GCB is opened after TransferDel the MCB is closed.
Hint:
This input simulates healthy Mains.
AMF StartBlock
This binary input can allow or block the AMF start. When the AMF start is blocked and Mains Fail will
come in AUT mode than the MCB breaker will stay closed.
DualAMFRole
This binary input could be used for switching between Master and Slave controller in Mutual Standby
Application (Dual AMF).
DualAMFCtrlIn
Control input for Mutual Standby Application. This binary input of controller 1 must be configured and
interconnected with binary output DualAMFCtrlOut of controller 2 for correct Mutual Standby function.
Hint:
More information about Dual mutual Standby is in chapter Stand-by Application.
Lang Selection
Not configured
Language selection is done only through the controller display. Pressing ENTER and PAGE buttons
concurrently and then only PAGE button separately.

ComAp intelilite nt amf25 Specifications

General

Communication Ports	RS232, RS485, USB
Power Supply	8-36 VDC
Number of Digital Inputs	8
Number of Digital Outputs	8
Number of Analog Inputs	3
Number of Analog Outputs	2
Display	LCD with backlight
Supported Protocols	Modbus
Operating Temperature	-20°C to +70°C
Humidity	95% non-condensing
Weight	0.4 kg
Protection	IP65 (front panel)
Controller Type	AMF Controller
Storage Temperature	-30 to +80 °C
