ComAp intelilite nt amf25 User Manual

InteliLite
NT
– AMF20/25, SW version 2.2, ©ComAp – September 2014 62
IL-NT-AMF-2.2-Reference Guide.pdf
The output opens, if
 alarm is not active and
 FAULT RESET is pressed
AL Overcurrent
Output closes if the generator
*IDMT over current or
current unbalance or
short current alarm activates.
The output opens, if
Alarm is not active and
FAULT RESET is pressed
AL BatteryFail
Output closes when IL-NT performs reset during start procedure (probably due to weak battery) or
when battery under/over voltage warning appears.
The output opens, if
 alarm is not active and
 FAULT RESET is pressed
AL EarthFault
Output closes when Earth Fault Current is detected (extension module is needed).
The output opens, if
 alarm is not active and
 FAULT RESET is pressed
Hint:
For more details see chapter Earth Fault Measurement
AL Common Wrn
Output closes when any warning alarm appears.
The output opens, if
 No warning alarm is active and
 FAULT RESET is pressed
AL Common Sd
Output closes when any shut-down alarm appears.
The output opens, if
 No Sd alarm is active and
 FAULT RESET is pressed
AL Common BOC
The output closes when any BOC alarm appears.
The output opens, if:
 No BOC alarm is active and
 FAULT RESET is pressed
AL Common Fls
Output closes when any Sensor Fail alarm appears.
The output opens, if
 No warning alarm is active and
 FAULT RESET is pressed
AL AI1 Sd
Output closes if the engine oil pressure (configured to the first analog input) shutdown alarm activates.
The output opens, if

ComAp intelilite nt amf25 Specifications

General

Communication Ports	RS232, RS485, USB
Power Supply	8-36 VDC
Number of Digital Inputs	8
Number of Digital Outputs	8
Number of Analog Inputs	3
Number of Analog Outputs	2
Display	LCD with backlight
Supported Protocols	Modbus
Operating Temperature	-20°C to +70°C
Humidity	95% non-condensing
Weight	0.4 kg
Protection	IP65 (front panel)
Controller Type	AMF Controller
Storage Temperature	-30 to +80 °C
