ComAp IS-NTC-BB Reference Guide

IGS-NT Combi, SW Version 3.0, ©ComAp – May 2013
IGS-NT-Combi-3.0 Reference Guide.PDF
115
Setpoint: Vg InpRangeSel
Group
Basic settings
Range [units]
277V, 120V [-]
Related FW
3.0
Description
This setpoint selects the range of the generator voltage terminals. The 120V
range is available only in IG-NTC and IS-NT. The IG-NT has the range adjusted
fixedly to 277V regardless of this setpoint.
NOTE:
The 277V range is suitable for both European (230V) and American (277V)
measurement. The range 120V is intended for high-voltage applications where
voltage transformers with 100V secondary range are used or for alternative
American (120V) measurement.
Setpoint: Vm VT ratio
Group
Basic Settings
Range [units]
0.1 .. 500.0 [V/V]
Related FW
3.0
Description
The setpoint is used to adjust the mains voltage transformers ratio.
NOTE:
Adjust the setpoint to the value of 1.0 if the mains voltage is connected directly to
the controller terminals, i.e. without transformers.
NOTE:
Example: if you have transformers with ratio 6000/100V adjust the setpoint to the
value of 60.0.
NOTE:
The range of the mains voltage inputs must be adjusted properly. See the setpoint
Vm InpRangeSel.
Setpoint: Vm InpRangeSel
Group
Basic settings
Range [units]
277V, 120V [-]
Related FW
3.0
Description
This setpoint selects the range of the mains voltage terminals. The 120V range is
available only in IG-NTC and IS-NT. The IG-NT has the range adjusted fixedly to
277V regardless of this setpoint.
NOTE:
The 277V range is suitable for both European (230V) and American (277V)
measurement. The range 120V is intended for high-voltage applications where
voltage transformers with 100V secondary range are used or for alternative
American (120V) measurement.
Setpoint: Vb InpRangeSel
Group
Basic settings
