IGS-NT Combi, SW Version 3.0, ©ComAp – May 2013
IGS-NT-Combi-3.0 Reference Guide.PDF
Value: Gen curr L1
Generator current in phase L1.
NOTE:
The ratio between the current measured at the input terminals and the displayed
current is adjusted by the setpoints CT ratio prim and CT ratio sec.
Value: Gen curr L2
Generator current in phase L2.
NOTE:
The ratio between the current measured at the input terminals and the displayed
current is adjusted by the setpoints CT ratio prim and CT ratio sec.
Value: Gen curr L3
Generator current in phase L3.
NOTE:
The ratio between the current measured at the input terminals and the displayed
current is adjusted by the setpoints CT ratio prim and CT ratio sec.
Value: Gen V unbal
Generator voltage unbalance. The value is calculated as maximal difference of
two phase voltages at one moment and expressed in % of the nominal voltage.
NOTE:
This value can be used for creating the generator voltage unbalance protection
using the "universal analog protections".
Value: Gen I unbal
