ComAp IS-NTC-BB Reference Guide

IGS-NT Combi, SW Version 3.0, ©ComAp – May 2013
IGS-NT-Combi-3.0 Reference Guide.PDF
300
Using these inputs for language selection is an option only. If the inputs are not
configured, the language can be selected using the menus on the terminal.
ENCODING TABLE
LANGUAGE INDEX
INPUT A
INPUT B
INPUT C
0
0
0
0
1
1
0
0
2
0
1
0
3
1
1
0
4
0
0
1
5
1
0
1
6
0
1
1
7
1
1
1
NOTE:
"0" in the table means the input is not active or not configured.
NOTE:
Language index 0 selects the default language of the terminal, i.e. the language,
which is adjusted in the terminal using it's menus.
NOTE:
The reaction on changes of these inputs is delayed about 1 sec to ensure the new
combination is valid (e.g. if a rotary selector switch is used).
CAUTION!
Each language change causes the reinitialization of the display. Function of the
controller is not influenced.
Binary input: User mask 1
Related FW
3.0
Description
This input allows user to activate chosen function in ScreenEditor (tool for
GenConfig) for particular screen instrument. User may choose from the following
functions:
NONE
SHOW
HIDE
No action
regarding this
screen
instrument is
taken.
By default the screen
instrument is hidden. If any
of mask inputs (User mask 1,
User mask 2, User mask 3,
User mask 4 or other
switches) connected to this
particular screen instrument
is activated, this screen
instrument is shown.
By default the screen
instrument is shown. If any of
mask inputs (User mask 1,
User mask 2, User mask 3,
User mask 4 or other
switches) connected to this
particular screen instrument
is activated, this screen
instrument is hidden.
E.g. this function can be used to "swap" between two different screen instruments
when certain conditions are fulfilled. Logical binary inputs Mask 1..4 can be used
